| Small
SMT___________________________ |
|
- pictures
link to product pages - |
|
P502 Small
SMT + Modules Snap-ApartTM
Our widest variety, with common circuits too.
SO, SOT23,
SC90, MSOP, DPAK, more.
Pin Strips Included. |
|
P513 Small
SMT Snap-ApartTM
150 patterns on both sides. SC, SOT23,
SOT323, TSOP, MSOP8/10, many more.
Pin Strips Included. |
|
|
|
| SOIC________________________________ |
|
- pictures
link to product pages - |
P505 SOIC
Snap-ApartTM
SOIC wide variety: 8, 14, 16, 20, 24, 32,
and 40 with small
SMT, through-hole pads.
Pin Strips Included. |
|
P510 SO8
to DIP .300" Snap-ApartTM
140 SOIC 8 to DIP .300"
For prototyping, or DIP to SMT
retrofit.
Pin Strips Included.
|
| |
|
|
P511 SOIC
to DIP .300" Snap-ApartTM
SOIC 8, 14, 16, 18, and 20, narrow/wide.
63 general-purpose
SOIC to DIP adapters.
Pin Strips Included. |
|
P514 SOIC
Narrow to DIP .300" Snap-ApartTM
SOIC 8, 14, 16, 18, and 20, narrow.
72 general-purpose SOIC
to DIP adapters.
Pin Strips Included. |
|
|
|
P515 SOIC
to DIP .600" Snap-ApartTM
SOIC 24, 28, 32 narrow/wide.
30 general-purpose SOIC to DIP
adapters.
Pin Strips Included. |
|
|
| |
|
|
| Fine Pitch
Dual-Row IC________________ |
|
- pictures
link to product pages - |
P503 Dual
Row SMT Snap-ApartTM
A very wide variety of
dual-row: SOIC, MSOP,
TSOP, QSOP, SSOP/TSSOP.
Pin Strips Included. |
|
P507
SSOP/TSSOP Snap-ApartTM
20 SSOP / TSSOP patterns,
both sides.
16/20/32/40 leads; .65, .5, and .4mm pitch.
Pin Strips Included. |
| |
|
|
P516 .65mm
TSSOP to DIP Snap-ApartTM
54 SSOP or TSSOP to DIP, for
14, 16, 20, and 28 pin devices. .65mm pitch TSSOP only.
Pin Strips Included. |
|
P517
TSSOP48 to DIP 600 Snap-ApartTM
18 SSOP/TSSOP
48 pin to DIP .600.
Fits .65, .5, and .4mm pitch.
Pin Strips Included. |
| |
|
|
P536 .5mm TSSOP to DIP Snap-ApartTM
54 SSOP or TSSOP to DIP, for
14, 16, 20, and 28 pin devices. .5mm pitch TSSOP only.
Pin Strips Included. |
|
P537 .4mm TSSOP to DIP Snap-ApartTM
54 SSOP or TSSOP to DIP, for
14, 16, 20, and 28 pin devices. .4mm pitch TSSOP only.
Pin Strips Included. |
|
|
|
| PitchSticksTM________________________ |
|
- pictures
link to product pages - |
P508
PitchSticksTM Metric Plus
48 inline SMT pads to
.100".
Ten metric and rare SMT pad pitches.
Pin Strips Included.
Snaps apart to become:
 x10
of various pad pitches. |
|
P509
PitchSticksTM 50 and 25 mil
48 inline SMT pads to .100".
50 and 25 mil SMT pad pitches.
Pin Strips Included.
Snaps apart to become:
 x10
of various pad pitches. |
| |
|
|
P534
PitchSticksTM .5mm / .65mm
48 inline SMT pads to
.100".
.5mm and .65mm SMT pad pitches.
Pin Strips Included.
Snaps apart to become:
 x9
of various pad pitches. |
|
|
